MXF workflow

Convert MXF for Avid Media Composer

Try Avid native linking first, then create a DNxHD editing copy when the source MXF codec remains unsupported.

Download for WindowsWindows 7-11, 64-bit Download for MacmacOS 10.13 or later
  • MXF mediaCamera or broadcast MXF
  • Choose DNxHDOutput matched to this workflow
  • Avid Media Composer checkVerify before batch processing

Problem and solution

Identify the MXF codec before choosing a workflow.

Check the codec, audio layout, metadata, and camera folder structure, then confirm what the destination can import directly.

Use Avid linking before transcoding

MXF is a container used by several camera and broadcast families. Current Avid Media Composer workflows can link to many supported MXF variants, so start with the original media and its complete folder structure.

Create a DNxHD editing copy only when the source codec or metadata remains unsupported or playback is unreliable. Match the project resolution and frame rate, then check picture, audio, timecode, and sync before converting the full batch.

Scope of the DNxHD workflow

The Avid DNxHD profile shown below provides HD 1080P and HD 720P choices. Use it when an HD editing copy matches the project. For a project that must retain 4K or another unsupported raster, do not choose an HD profile just to resolve an import error; first confirm a format and resolution supported by the Avid project. This guide does not demonstrate a 4K DNxHR workflow.

Solution direction

Apply the solution in the workflow below.

Try Avid native linking first, then create a DNxHD editing copy when the source MXF codec remains unsupported.

Three-step workflow

Create and verify one test output before processing the full batch.

Try Avid native linking first, then create a DNxHD editing copy when the source MXF codec remains unsupported.

01

Add the source

Load the MXF clips

Open LosslessConverter and select Add Files. Add the MXF clips and select the files required for this workflow.

LosslessConverter main window with the source controls visible
Source toolbarLoad the source from the main toolbar.
02

Match the Avid editor

Choose Editing > Avid DNxHD

Open Output Format, select the Editing group, and choose Avid DNxHD. Use HD 1080P or HD 720P to match the project resolution.

LosslessConverter Output Format menu with Editing and Avid DNxHD selected
Avid DNxHDSelect Editing, then choose Avid DNxHD.
03

Create the current output

Select Start All, then verify in Avid Media Composer

Choose an output folder and select Start All. When processing finishes, import the DNxHD MOV files into Avid Media Composer and verify picture, frame rate, timecode, and audio.

LosslessConverter main window showing the Start All control at the lower right
Start AllRun the task, then verify the result.

Process your own media

Process one file, verify the result, then run the full batch.

Download for WindowsWindows 7-11, 64-bit Download for MacmacOS 10.13 or later Browse MXF Solutions

Primary sources

Official references for this workflow

Use these first-party references to confirm current format, application, or device support. Capabilities can change after this guide is updated.

  • Avid: File support without QuickTime

    Review the documented Media Composer version and operating-system limits for linking and importing without QuickTime. This is not a compatibility list for every release.
